Rack capacity choice: Ranging from 2 to 10, enabling tailored scalability
AC unit choice: 4kW, 8kW, 12kW, 16kW, 23kW, and 38kW.
UPS unit choice: 6kVA, 10kVA, 15kVA, 20kVA, 30kVA, and 40kVA.
Monitoring: Tracking temperature, humidity, smoke, UPS, PDU and AC.
Management: Centralizing control, diagnosing faults, and tracking assets.
Alarm: Delivering real-time alerts via SMS, sound, phone, and display.
Emergency cooling: Using room air for backup during AC failure
Mixed cooling: Combining natural cold sources with AC to save energy.
High-efficiency variable-frequency AC: Equipped with a variable-frequency AC system, reduces energy consumption.
Mixed cooling system: By incorporating free air and allowing for mixed-mode or free-air mode, AC can be disengaged when not required, further reducing energy consumption.
Expansion Cabinet Option: Supports the addition of up to 10 cabinets, enabling seamless expansion of IT infrastructure as needs grow.
Upgradable Cooling Capacity: Provides up to 38 kW AC unit, ensuring optimal performance.
Upgradable UPS: Provides up to 40kVA UPS unit, maintaining uptime and preventing interruptions.
Comprehensive monitoring: Tracking all critical infrastructure performances with DCIM.
Remote management: Enabling off-site system management.
Proactive maintenance: Detecting faults early to prevent downtime.
| Product tech specifications | FlexLinear |
Cabinet quantity | 2-10 |
Cooling capacity option | 4kW, 8kW, 12kW, 16kW, 23kW, 38kW |
Free cooling system | √ |
Operating power supply | Voltage 220V-250V, frequency:50Hz |
Height (mm) | 2000 |
Width per cabinet(mm) | 1200 |
Depth (mm) | 1200 |
PDU | 2* 32A Input, 16 ports each |
UPS option | 6kVA/5.4kW, 10kVA/9kW, 15kVA/13.5kW, 20kVA/18kW, 30kVA/27kW, 40kVA/36kW |
Battery backup time | According to actual needs |
DCIM system | Displayed on standard, 10-inch touch screen |
Fire protection module | Optional |
Accessories | •Shelf •Blank panels •Cable management board •Background light and power •Remoted controlled door •Fingerprint recorder |
